Ryan Audio is proud to announce the official arrival of the brand-new RYAN AUDIO PD Series Car Amplifiers! Engineered for precision, efficiency, and relentless power delivery, the PD series is built to elevate your mobile audio setup to competitive standards.Whether you are building a crystal-clear multi-channel front stage or driving dedicated sub-bass authority, the PD lineup delivers uncompromising performance. Available in two configurations:
RYAN AUDIO PD80.4
Class D 4-Channel Full Range Amplifier Designed for clean, dynamic, and powerful full-range reproduction with incredible installation flexibility.
Power Output (4 ohms): 4ch x 80 Watts
Power Output (2 ohms): 4ch x 120 Watts
Bridged (4 ohms): 2ch x 220 Watts
THD+N: <0.15%
Signal-to-Noise Ratio: >90 dB
Frequency Response (-1 dB): 20 Hz to 20 kHz
High-Pass Filter (HPF – 12 dB/Oct): 40 Hz – 2 kHz
Low-Pass Filter (LPF – 12 dB/Oct): 40 Hz – 500 Hz
Bass Gain Control: 12 dB
RYAN AUDIO PD700.1
Class D 1-Channel Mono Amplifier A compact powerhouse engineered to drive subwoofers with deep, stable, and hard-hitting authority.
Power Output (1 ohm): 1ch x 750 Watts
Power Output (2 ohms): 1ch x 510 Watts
Power Output (4 ohms): 1ch x 320 Watts
THD+N: <0.2%
Signal-to-Noise Ratio: >85 dB
Frequency Response: 10 Hz – 245 Hz
Subsonic Filter: 10 Hz – 50 Hz
Low-Pass Filter (LPF – 12 dB/Oct): 50 Hz – 200 Hz
Bass Gain Control: 12 dB
Bass Remote Control: Ready
